DCAM710
TOF+RGB
Evaluation Kit, normal application
-
Sensors: TOF CCD+RGB Sensor
-
Laser emitter: 850 or 940nm, VCSEL
-
TOF depth/IR resolution: 640*480, 30FPS
-
RGB image resolution: 1920*1080, 30FPS
-
Depth sensing FOV: 69°(H)*51°(V) for 850nm/58°(H)*44°(V) for 940nm
-
Output format: RAW12 (depth & IR), MJPEG (RGB)
-
Interface: USB 2.0
-
Indicator: RGB LED
-
Power supply: 5V (via USB) or/and 5V-6V (via DC)
-
Working range: 0.2m-8m
-
Working temperature: -10℃-50℃
-
OS compatibility: Android/Linux/Windows7/8/10
-
Built-in depth sensing algorithms

DCAM305

TOF+RGB
Face Recognition
-
Sensors: TOF CCD+RGB Sensor
-
Laser emitter: 940nm,VCSEL
-
TOF depth/IR resolution: 480*640,15FPS
-
RGB image resolution: 1080*1920,30FPS
-
Depth sensing FOV: 45.4°(H)*58.6°(V)
-
RGB sensing FOV: 50.1°(H)*79.9°(V)
-
Output format: RAW12 (depth, IR), H.264/MJPEG (RGB)
-
Interface: USB 2.0
-
Indicator: RGB LED
-
Power supply: 5V (via USB)
-
Working range: 0.3m-1.2m
-
Working temperature: -20℃-50℃
-
OS compatibility: Android/Linux/Windows7/8/10
-
Built-in depth sensing algorithms

.png)
DCAM500
TOF only
Commercial Class
-
Sensors: TOF CCD
-
Laser emitter: 850 or 940nm,2*VCSEL
-
TOF resolution: 640*480,30FPS
-
Depth sensing FOV: 69°(H)*51°(V) (Customizable)
-
Output format: RAW12 (depth, IR)
-
Interface: USB 2.0 Type B, RS-232
-
Indicator: RGB LED
-
Power supply: 5V (via USB) or/and 5V-9V (via DC)
-
Working range: 0.2m-6m (Customizable)
-
Working temperature: -20℃-50℃
-
OS compatibility: Android/Linux/Windows7/8/10
-
Algorithm/Software: C/C++ SDK, OpenNI, ROS


DCAM550
TOF only
For AGV/AMR
-
Sensors: TOF CCD
-
Laser emitter: 850/940nm (Selectable),2*VCSEL
-
TOF resolution: 640*480,30FPS
-
Depth sensing FOV: 69°(H)*51°(V) for 850nm/ 58°(H)*44°(V) for 940nm (Customizable)
-
Output format: RAW12 (depth, IR)
-
Interface: USB 2.0 Type A/Ethernet (Selectable), DC Jack
-
Indicator: RGB LED
-
Power supply: 5V (via USB)/PoE (Selectable), 5V-9V (via DC)
-
Working range: 0.2m-8m (Customizable)
-
Working temperature: -20℃-50℃
-
OS compatibility: Android/Linux/Windows7/8/10
-
Algorithm/Software: C/C++ SDK, OpenNI, ROS


DCAM550-P
DCAM550-U
New
Product
TOF only
For AGV/AMR

DCAM800
TOF only
Industrial Class
-
Sensors: TOF CCD
-
Laser emitter: 850 or 940nm,4*VCSEL
-
TOF resolution: 640*480,30FPS
-
Depth sensing FOV: 69°(H)*51°(V) (Customizable)
-
Output format: RAW12(depth, IR)
-
Interface: Ethernet, CAN Bus
-
Power supply: DC 12V-24V or POE+
-
Working range: 0.2-10m (Customizable)
-
Working temperature: -20℃-50℃
-
OS compatibility: Android/Linux/Windows7/8/10
-
Built-in depth sensing algorithms

DCAM800 Lite
TOF only
Industrial Class, lower price
-
Sensors: TOF CCD
-
Laser emitter: 850 or 940nm,4*VCSEL
-
TOF resolution: 640*480,30FPS
-
Depth sensing FOV: 69°(H)*51°(V) (Customizable)
-
Output format: RAW12(depth, IR)
-
Interface: USB 2.0 Type B, RS-232, 100M Ethernet
-
Power supply: USB Type B 2.0, or/and DC 9V-16V
-
Working range: 0.2-10m (Customizable)
-
Working temperature: -20℃-50℃
-
OS compatibility: Android/Linux/Windows7/8/10
-
Built-in depth sensing algorithms


DCAM10
TOF only
MIPI Product
-
Sensors: TOF CCD
-
Laser emitter: 850 or 940nm,



DCAM20
TOF only
MIPI Product
-
Sensors: TOF CCD
-
Laser emitter: 850 or 940nm,



DCAM80
TOF only
MIPI Product
-
Sensors: TOF CCD
-
Laser emitter: 850 or 940nm,4*VCSEL
-
TOF resolution: 640*480,30FPS
